Why Should I Rent a Boom Lift?
Boom lifts are powerful tools equipped with a stable, articulating platform that allows workers to navigate both wide and narrow vertical spaces. This makes them ideal for tasks requiring precision,
$51,400.00
Work Height Max.
Platform Capacity
Machine Width
Max Platform Height: 14.7 m
Max Working Height: 16.7 m
Max Horizontal Extension: 8.5 m
Length (Stowed): 7.49 m
Width (Stowed): 2.30 m
Height (Stowed): 2.28 m
Wheelbase: 2.30 m
Ground Clearance: 0.35 m
Platform Dimensions (L×W×H): 1.83 × 0.85 × 1.10 m
Platform Capacity: 300 kg
Turntable Rotation: 360° (Continuous / 355° Non-continuous optional)
Platform Rotation: 180°
Drive Speed (Stowed): 4.5 km/h
Drive Speed (Raised): 1.0 km/h
Gradeability: 40%
Turning Radius (Inside): 1.82 m
Turning Radius (Outside): 4.78 m
Turntable Tailswing: 0.10 m
Tilt Rating: 5°
Drive & Steer: 4WD × 2WS
Tyres: 33×12D610 (Foam-filled) / 33×12-20 (Solid)
Engine Power Options:
18.2 kW @ 3000 rpm (Kubota D1105, EU Stage V / China IV)
43.2 kW @ 2400 rpm (Kubota V2403-CR-TIE4B-SBM-2, EPA Tier 4)
36.0 kW @ 2600 rpm (Kubota V2403BM-DI-CT04, China IV)
Auxiliary Power Unit: 12 V DC
Fuel Tank Capacity (Diesel): 55 L
Hydraulic Tank Capacity: 112 L
Machine Weight: 7,700 kg (18.2 kW engine) / 8,070 kg (36 kW engine)
Standards Compliance: CE / ANSI / CSA / AS / EAC
