$82,300.00
Work Height Max.
Platform Capacity
Machine Width
Max Platform Height：32.3 m
Max Working Height：34.3 m
Max Horizontal Extension：17.9 m (Restricted) / 20.0 m (Restricted) / 20.9 m (Unrestricted)
[A] Length – Stowed：12.76 m
[B] Width：2.49 m
[C] Height – Stowed：2.88 m
[D] Wheelbase：3.0 m
Ground Clearance：0.42 m
Platform Dimensions (L×W×H)：2.44 × 0.91 × 1.10 m
Platform Capacity (Unrestricted)：250 kg
Platform Capacity (Restricted)：300 kg / 454 kg
Turntable Rotation：360° (Continuous)
Platform Rotation：160°
Drive Speed – Stowed：0 – 4.8 km/h
Drive Speed – Raised：0 – 1.1 km/h
Gradeability：45%
Turning Radius – Inside：3.65 m
Turning Radius – Outside：6.91 m
Turntable Tailswing：1.45 m
Tilt Rating：5°
Drive / Steer：4WD × 2WS
Tyres：385/65D22.5 (Foam-filled)
Power Source (Optional)：
54 kW @ 2400 rpm (Cummins / China T3)
55.4 kW @ 2600 rpm (TD2.9, EU Stage V / EPA Tier 4F)
36.8 kW @ 2200 rpm (Yuchai / China T4)
36.5 kW @ 2400 rpm (Yuchai / China T3)
Auxiliary Power Unit：12 V DC
Fuel Tank Capacity (Diesel)：150 L
Hydraulic Tank Capacity：180 L
Weight：17,460 kg
Standards Compliance：CE / ANSI / EAC
