Sinoboom Telescopic Boom Lift TB58RJ PLUS (TB1900RJ PLUS)

Sinoboom Telescopic Boom Lift TB58RJ PLUS (TB1900RJ PLUS)

$219,100.00

59.9 m

Work Height Max.

454 kg

Platform Capacity

2.49 m

Machine Width

Facebook
Twitter
LinkedIn

Product Parameter

DIMENSIONS

  • Max Platform Height: 57.9 m
  • Max Working Height: 59.9 m
  • Max Horizontal Extension: 21.01 m / 24.4 m (Restricted / Unrestricted)
  • Length (Stowed): 20.07 m
  • Width: 2.49 m
  • Height (Stowed): 3.1 m
  • Wheelbase: 5.2 m
  • Ground Clearance: 0.44 m
  • Platform Dimensions (L×W×H): 2.44 × 0.91 × 1.1 m

PERFORMANCE

  • Platform Capacity (Unrestricted): 300 kg
  • Platform Capacity (Restricted): 454 kg
  • Turntable Rotation: 360° (Non-continuous)
  • Platform Rotation: 160°
  • Drive Speed (Stowed): 4.5 km/h
  • Drive Speed (Raised): 0.48 km/h
  • Turning Radius (Inside): 7.1 m / 2.28 m (Outrigger retracted / extended)
  • Turning Radius (Outside): 9.52 m / 6.54 m (Outrigger retracted / extended)
  • Gradeability: 45%
  • Turntable Tailswing: 2.32 m
  • Tilt Rating:
  • Drive / Steer: 4WD × 4WS
  • Tyres: 445/50D710 24PR (Foam-filled)

POWER

  • Engine Options: 74 kW @ 2200 rpm – YCF36100 (China T4) 74 kW @ 2200 rpm – Cummins QSF3.8 (China T3) 74.4 kW @ 2300 rpm – DEUTZ TCD3.6 L4 (Stage V / T4f)
  • Auxiliary Power: 12V DC
  • Fuel Tank Capacity: 200 L
  • Hydraulic Tank Capacity: 405 L

OTHER

  • Machine Weight: 27,600 kg
  • Standards Compliance: CE / EAC
