Power: 199KW
Fuel Tank Capacity: 480L
Dimensions: 5980×3642×3460mm
| 240 Horsepower Bulldozer Performance Parameters | |
|---|---|
| Performance Parameters | |
| Operating Weight (excluding ripper) | 24300kg |
| Minimum Turning Radius | 3120mm |
| Ground Contact Length | 3050mm |
| Ground Pressure | 0.062kPa |
| Engine | |
| Engine Model | Weichai WP13gG271E471 |
| Power/Speed | 199kW/1900rpm |
| Dimensions | |
| Overall Dimensions | 5980×3642×3460mm |
| Travel Performance | |
| Forward Speed | F1:0–3.8km/h, F2:0–6.9km/h, F3:0–11.8km/h |
| Reverse Speed | R1:0–4.5km/h, R2:0–8.1km/h, R3:0–14.2km/h |
| Chassis System | |
| Ground Clearance | 405mm |
| Track Center Distance | 2000mm |
| Track Width | 560/610/660mm |
| Number of Track Plates (per side) | 41 |
| Pitch | 216mm |
| Number of Rollers (per side) | 7 |
| Number of Support Rollers (per side) | 7 |
| Fuel Tank Capacity | |
| Fuel Tank | 480L |
| Hydraulic Tank | 110L |
| Blade | |
| Blade Type | Straight Tilt Blade (Angle Blade / Semi-U Blade) |
| Blade Weight | 3239kg (2958/3500kg) |
| Blade Width | 3642mm (3723/3795mm) |
| Blade Height | 1377mm (1380/1406mm) |
| Maximum Lifting Height | 1210mm |
| Maximum Cutting Depth | 540mm |
| Ripper | |
| Ripper Type | Single tooth / Three tooth |
| Ripper Weight | 2900kg |
| Maximum Ripping Depth | 695mm / 666mm |
| Maximum Lifting Height | 515mm / 555mm |
