Power: 257KW
Fuel Tank Capacity: 640L
Dimensions: 6680×4130×3688
| 320 Horsepower Bulldozer Performance Parameters | |
|---|---|
| Performance Parameters | |
| Operating Weight (excluding ripper) | 37200kg |
| Minimum Turning Radius | 3.8m |
| Ground Contact Length | 3150mm |
| Ground Pressure | 0.105kPa |
| Engine | |
| Engine Model | Cummins NT855-C360 |
| Power/Speed | 257kW/2000rpm |
| Dimensions | |
| Overall Dimensions | 6690×4130×4688mm |
| Travel Performance | |
| Forward Speed | F1:0–3.6km/h, F2:0–6.6km/h, F3:0–11.5km/h |
| Reverse Speed | R1:0–4.4km/h, R2:0–7.8km/h, R3:0–13.5km/h |
| Chassis System | |
| Ground Clearance | 500mm |
| Track Center Distance | 2140mm |
| Track Width | 560mm |
| Number of Track Plates (per side) | 41 |
| Pitch | 228.6mm |
| Number of Rollers (per side) | 2 |
| Number of Support Rollers (per side) | 7 |
| Fuel Tank Capacity | |
| Fuel Tank | 640L |
| Hydraulic Tank | 164L |
| Blade | |
| Blade Type | Straight Tilt Blade / Angle Blade / Semi-U Blade |
| Blade Capacity | 10.6m³ / 11.9m³ |
| Blade Weight | 4520kg / 4855kg / 4868kg |
| Blade Width | 4130mm / 5000mm / 4300mm |
| Blade Height | 1590mm / 1740mm / 1725mm |
| Maximum Lifting Height | 1560mm / 1703mm / 1560mm |
| Maximum Cutting Depth | 560mm / 630mm / 560mm |
| Ripper | |
| Ripper Type | Single tooth / Three teeth |
| Ripper Weight | 4260kg / 4800kg |
| Maximum Ripping Depth | 1250mm / 842mm |
| Maximum Lifting Height | 955mm / 883mm |
| Winch | |
| Winch Type | / |
| Hydraulic Motor Model | / |
| System Pressure | / |
| First Layer Maximum Pressure | / |
| First Layer Maximum Line Speed | / |
| Number of Layers | / |
| Wire Rope Size | / |
