$38,000.00
Max. Working Height：18m
Platform Capacity：680kg
| Size | |
| Work Height | 18m |
| A- Platform Height – Elevated | 16m |
| B- Platform Height – Stowed | 2.02m |
| C- Platform Dimension (Length) | 3.26m |
| D- Platform Dimension (Width) | 1.83m |
| Platform Extension | 1.3m |
| Overall Height (Rails Up) | 3.16m |
| E- Overall Height (Rails Down) | 2.47m |
| F- Overall Length | 4.88m |
| G- Overall Width | 2.3m |
| H- Wheelbase | 2.9m |
| I- Ground Clearance | 0.275m |
| Performance | |
| Platform Capacity | 680kg |
| Capacity on Deck Extension | 230kg |
| Drive Height | 9m |
| Max. Number of Workers | 4 |
| Drive Speed (Stowed) | 8.5km/h |
| Drive Speed (Raised) | 0.5km/h |
| Turning Radius (Inside) | 2.75m |
| Turning Radius (Outside) | 5.8m |
| Up/Down Time | 80s / 65s |
| Gradeability | 40% (22°) |
| Max. Working Slope (Lateral/Vertical) | 2° / 3° |
| Drive | 4WD |
| Tire | 315/55 D20 Foam-filled Tires 23×12-20.8 Solid Tires |
| Power | |
| Engine | Kubota V2403 38kw/2600rpm (EU II) / Kubota V2403 38.8kw/2700rpm (EU V) |
| Fuel Tank Capacity | 105L |
| Hydraulic Tank Capacity | 100L |
| Weight | |
| Gross | 8850kg |
