Why Should I Rent a Boom Lift?
Boom lifts are powerful tools equipped with a stable, articulating platform that allows workers to navigate both wide and narrow vertical spaces. This makes them ideal for tasks requiring precision,
$12,000.00
Max. Working Height：13.80m/10m
Platform Capacity：350kg
| Size | |
| Work Height | 13.80m / 10m |
| A- Platform Height – Elevated | 11.80m / 8m |
| B- Platform Height Stowed | 1.52m |
| C- Platform Length | 2.30m |
| D- Platform Width | 1.12m |
| Platform Extension | 0.91m |
| E- Overall Height (Rails Up) | 2.86m |
| Overall Height (Rails Down) | 1.92m |
| F- Overall Length | 2.49m |
| G- Overall Width | 1.15m |
| H- Wheelbase | 1.85m |
| I- Ground Clearance (Stowed) | 0.11m |
| J- Ground Clearance (Raised) | 0.02m |
| Performance | |
| Platform Capacity | 350kg |
| Capacity on Deck Extension | 113kg |
| Max. Number of Workers | 2 (Indoor) / 1 (ANSI) |
| Drive Speed (Stowed) | 3.5km/h |
| Drive Speed (Raised) | 0.8km/h |
| Turning Radius (Inside) | 0.1m |
| Turning Radius (Outside) | 2.2m |
| UpDown Drive Motor | 24V / 3.3KW |
| UpDown Time | 62s / 42s |
| Gradeability | 25% (14°) |
| Max. Working Slope (Lateral/Vertical) | 1.5° / 3° |
| Control | Proportional Control |
| Drive | Front Wheels |
| Brake | Front Wheels |
| Tire | Ø381mm × 127mm |
| Power | |
| Battery | 230Ah Li-ion |
| Charger | 24V / 30A |
| Weight | |
| Gross | 2970kg |
