¥100.00
Working height：10m
Load capacity: 450kg
Platform size：2271*1110mm
| Platform capacity | 450kg |
|---|---|
| Extension capacity | 113kg |
| Length(L) | 2480mm |
| Width(W) | 1190mm |
| Height(rail up) | 2250mm |
| Height(rail down) | 1535mm |
| Platform size | 2271x1110mm |
| Extension | 900mm |
| Ground clearance (folded) | 100mm |
| Ground clearance (raised) | 20mm |
| Wheel base | 1890mm |
| Turning radius (inner) | 0mm |
| Turning radius (outer) | 2200mm |
| Lifting motor | 24/4.5V/Kw |
| Rising/lowering speed | 3-5min |
| Travel speed (folded) | 3.5Km/h |
| Travel speed (raised) | 0.8Km/h |
| Battery | 4×12/200V/Ah |
| Charger | 24/30V/A |
| Grade ability | 25% |
| Max. slope | 1.5/3。 |
| Tires | Φ381×127mm |
| Overall weight | 2200kg |
GMH is located in Jinan, Shandong Province, which is the hometown of China’s lifting platform. We have more than 20 years of experience, and we successfully completed the design and production of various platforms. No matter what complex operating environment, we can always provide users with high-quality high-altitude operation solutions.
