Max. Pile Diameter
Max. Pile Depth
Operating Weight
| CFA Mode | |
| Crowd Force | / kN |
| Stroke | 17060 mm |
| Overall Height | 29775 mm |
| Max. Pile Diameter | 1000 mm |
| Max. Pile Depth | 24 m |
| Operating Weight | 90 T |
| Line Pull | 770 kN |
| Rated Speed | 5–30 rpm |
| Rated Output Torque | 100–230 kN·m |
| Standard Mode | |
| Crowd Force | 210 kN |
| Stroke | 15000 mm |
| Overall Height | 24050 mm |
| Max. Pile Diameter | 2000 mm |
| Max. Pile Depth | 73 / 56 m |
| Operating Weight | 86 T |
| Line Pull | 270 kN |
| Rated Speed | 5–30 rpm |
| Rated Output Torque | 235 kN·m |
| Main Chassis | |
| Base Engine | 6UZ1 |
| Engine Power | 257 kW / 2000 rpm |
| Emission Regulation | China Stage III |
| Low Headroom | |
| Crowd Force | 210 kN |
| Stroke | 4500 mm |
| Overall Height | 12135–13205 mm |
| Max. Pile Diameter | 2000 mm |
| Max. Pile Depth | 24 m |
| Operating Weight | 75 T |
| Line Pull | 270 kN |
| Rated Speed | 5–30 rpm |
| Rated Output Torque | 235 kN·m |
| Overall Machine | |
| Transport Width | 3550 mm |
| Transport Height | 3750 mm |
| Main Winch | |
| Lifting Capacity | 235 kN |
| Max. Line Speed | 70 m/min |
| Rope Diameter | 32 mm |
