Max. Pile Diameter
Max. Pile Depth
Operating Weight
| CFA Mode | |
| Crowd Force | / kN |
| Stroke | 18300 mm |
| Overall Height | 33075 mm |
| Max. Pile Diameter | 1200 mm |
| Max. Pile Depth | 25.5 m |
| Operating Weight | 108 T |
| Line Pull | 1000 kN |
| Rated Speed | 5–24 rpm |
| Rated Output Torque | 285 kN·m |
| Standard Mode | |
| Crowd Force | 260 kN |
| Stroke | 17100 mm |
| Overall Height | 25470 mm |
| Max. Pile Diameter | 2200 mm |
| Max. Pile Depth | 94 / 61 m |
| Operating Weight | 105 T |
| Line Pull | 355 kN |
| Rated Speed | 5–24 rpm |
| Rated Output Torque | 285 kN·m |
| Main Chassis | |
| Base Engine | 6WG1 |
| Engine Power | 300 kW / 1800 rpm |
| Emission Regulation | China Stage III |
| Low Headroom | |
| Crowd Force | 260 kN |
| Stroke | 4600 mm |
| Overall Height | 11655–13280 mm |
| Max. Pile Diameter | 2200 mm |
| Max. Pile Depth | 50 m |
| Operating Weight | 96 T |
| Line Pull | 355 kN |
| Rated Speed | 5–24 rpm |
| Rated Output Torque | 285 kN·m |
| Overall Machine | |
| Transport Width | 3475 mm |
| Transport Height | 3625 mm |
| Main Winch | |
| Lifting Capacity | 330 kN |
| Max. Line Speed | 70 m/min |
| Rope Diameter | 36 mm |
